HTRF MAb Anti-phospho SAP/JNK-Eu cryptate, 500 Assay Points

MAb Anti-phospho SAP/JNK-Eu cryptate enables the rapid detection of SAP/JNK phosphorylation on Thr183 &Tyr184 15 in a biochemical kinase assay format.

For research use only. Not for use in diagnostic procedures.
Product Variants
Part number: 61P09KAE
Unit Size: 500 Assay Points
List price: USD 622.06
Your price:
USD 622.06
USD 622.06 /each
Part number: 61P09KAZ
Unit Size: 10,000 Assay Points
List price: USD 1,739.00
Your price:
USD 0.00
USD 1,739.00 /each

Overview

The Anti-phospho SAP/JNK-Eu cryptate is a labeled monoclonal antibody enabling the rapid detection of SAP/JNK only when phosphorylated at Thr183 & Tyr185. It does not cross-react with phosphorylated forms of p44/42 or p38 MAPK. It does not detect the non-phosphorylated SAP/JNK. This allows the construction of a highly specific biochemical kinase assay. Any kind of substrate can be used, from small synthetic peptides to natural substrates, meaning high assay detection versatility. As HTRF tolerates extremely high ATP concentrations, an assay can be performed at physiological ATP concentrations.

Specifications

Assay Points
500
Assay Target Type
Fluorescent reagent
Assay Technology
HTRF
Brand
HTRF
Quantity
1
Therapeutic Area
Cardiovascular
Infectious Diseases
Inflammation
Metabolism/Diabetes
NASH/Fibrosis
Neuroscience
Oncology & Inflammation
Rare Diseases
Unit Size
500 Assay Points

Video gallery

How it works

Assay principle

HTRF kinase assays typically use a combination of a Europium-cryptate labeled anti-phosphoresidue antibody, SA-XL665 and a biotinylated* substrate. The signal is proportional to the concentration of phospho-residues. *Alternatively, other tags such as 6HIS, GST, c-myc, DNP, or FLAG may be used to label the kinase substrate.

HTRF MAb Anti-phospho SAPJNK-Eu cryptate 1.svg



Assay protocol

HTRF kinase assays have two basic phases: 1. Enzymatic step: biotinylated substrate is incubated with the kinase of interest and with the compounds in presence of co-factors. The reaction starts with the addition of ATP. 2. Detection step: The phosphorylated biotinylated substrate is then detected by the addition of Streptavidin-XL665 and MAb Anti-phosphoSAP/JNK-Eu cryptate , prepared in a buffer containing EDTA to stop the enzymatic reaction.

HTRF MAb Anti-phospho SAPJNK-Eu cryptate 2.svg



Resources

1-1 of 1 Resources
Guide
HTRF solutions, guide to major applications

This guide provides you an overview of HTRF applications in several therapeutic areas.

SDS, COAs, Manuals and more Illuminator

SDS, COAs, Manuals and more

Are you looking for technical documents for this product. We have housed them in a dedicated section., click on the links below to explore.
