JANUS G3 Mini Workstation, 4-Tip

Available to support volumes ranging from 1 μL to 5000 μL and offering 4 or 8 variable spanning pipetting configurations, the JANUS G3 Mini workstation is a fully capable, compact, and user-friendly automated liquid handling system.

With its support for up to 12 SBS deck locations, this workstation can easily be configured to execute various applications, including master mix creation, plate arrays, plate preparation, PCR, sample or reagent serial dilutions, and more!

For research use only. Not for use in diagnostic procedures.

  • YJS4001
    JANUS® G3 Mini Workstation, 4-Tip
  • YJS8001
    JANUS® G3 Mini Workstation, 8-Tip
  • The compact and simple-to-use automated liquid handling workstation.

    Key Applications:

    • PCR/qPR
    • Protein Purification
    • NGS
    • Nucleic Acid Isolation
    • ELISA
    • HLA-typing
    • Nuclear testing
    • Sanger
    • Cherry Picking
    • Normalization
    • Serial dilutions
    • DNA extraction from DBA
    • Cannabis (sample extraction/qPCR)

    These manual workflows, and many more, can be seamlessly automated on a JANUS Mini workstation.

    Product Features:

    • Use Disposable or Fixed (washable) pipette tips without any hardware changes, thanks to the VersaTip technology
    • Independent Z-motion, liquid level sensing and spanning Y-motion of the Varispan arm easily allow pipetting in labware such as tubes, microplates, deep well plates, troughs and vials.
    • Independent liquid level sensing, including aqueous, low or non-ionic polar solutions and solvents such as DMSO are possible with the patented Accursense technology.

    Software Features:

    • The JANUS G3 Mini Workstation is seamless to setup, create methods, and run protocols with the WinPrep® software and JANUS Application Assistant. This software allows users to quickly monitor research protocols, track sample processing and integrate other devices for fully automated application solutions.
    • Predefined labware definitions simplify assay set-up and enable labware definitions to remain independent of the position on the instrument.
    • The performance file library offers optimized pipetting performance parameters and the ability to modify pump speeds, air gaps, waste and blowout volumes, and liquid delays.

    Varispan Arm Options:

    • Fixed Tips: regular and low volume and VersaTip sampling tip
    • Disposable Tips: 20, 25, 50, 175, 200, 900, 1000 uL tips available. Conductive (black) and clear, filter, non-filter and sterile formats available
    • Syringe volumes: 250, 500, 1000, 2500, 5000 uL

    JANUS® G3 MINI Workstation Specifications:

    • Use Disposable or Fixed (washable) pipette tips without any hardware changes, thanks to the VersaTip technology
    • Independent Z-motion, liquid level sensing and spanning Y-motion of the Varispan arm easily allow pipetting in labware such as tubes, microplates, deep well plates, troughs and vials.
    • Independent liquid level sensing, including aqueous, low or non-ionic polar solutions and solvents such as DMSO are possible with the patented Accursense technology.
      • Operating Temperature: 59-95°F (15-35°C)
      • Operating REALITIVE HUMIDITY: 60 - 80% at 85°F (30°C) non-condensing
      • Power Input:
        • 100, 120 VAC 50-60 Hz, 525 VA
        • 200, 230 VAC 50-60 Hz, 525 VA
      • Certifications CE, CSA
        • 34" (864 mm) x 31" (788 mm) x With enclosure, JANUS G3 Mini Workstation measures: 38" (965 mm) x 40" (1016 mm) x 35" (890 mm) 33" (838 mm)
  • Volume %CV Tip/Head Condition
    5 ul < 2% 20 ul disposable tip Distilled water, 500 ul syringe
    50 ul < 1% Fixed tip Distilled water, 500 ul syringe



  • Brand
    JANUS
    Model Name
    JANUS® G3 Mini Workstation, 4-Tip
    Unit Size
    1 unit
